Schweizer / SGU 1-19
Glider Reg. Number: N91806
1946
Design & Development
The Schweizer SGU 1-19 and Schweizer SGU 1-20 are a family of United States single-seat, high-wing, strut-braced, utility gliders built by Schweizer Aircraft of Elmira, New York.
The 1-19 was a 1944 development of the pre-war SGU 1-7 and bears a strong resemblance to the earlier craft. It was designed for single place training and soaring flights.
The 1-20 was an improved version of the 1-19 with a wingspan of 43 feet (13 m) replacing the 36-foot (11 m) wing on the 1-19.
Specifications
Total Number Built: 57
Span: 36.66 ft 11.18 m
Length: 20.9 ft 6.38 m
Wing Area: 170 ft2 15.8 m2
Empty Weight: 320 lbs 145kg
Wing Loading 3.24 lbs/ft2 15.8 kg/m2
Gilde Ratio (est.): 16:1 @ 42 mph 68 km/h
Minimum rate of sink: 3.5 ft/sec @ 33 mph 1.1 m/sec @ 53 km/h
